Cause Effect Graph Technique | Examples

Cause Effect Graph-



  • Cause Effect Graph is a popular black box testing technique.
  • It illustrates the relationship between a given outcome and all the factors that influence the outcome graphically.





Here,

  • A “Cause” stands for a distinct input condition that fetches about an internal change in the system.
  • An “Effect” represents an output condition, a system state that results from a combination of causes.



Applications-



  • For analyzing the existing problem so that corrective actions can be taken at the earliest.
  • For relating the interactions of the system with the factors affecting a particular process.
  • For identifying the possible root causes, reasons for a particular effect, problem or outcome.



Advantages-



  • It helps to determine the root causes of a problem or quality.
  • It indicates possible causes of variation in a process.
  • It identifies those areas where data should be collected for further study.
  • It utilizes the team knowledge of the process by encouraging team participation.



Steps For Drawing Cause Effect Diagram-



The following steps are followed-

  • Identify and describe the input conditions (causes) and actions (effect).
  • Build up a cause-effect graph.
  • Convert cause-effect graph into a decision table.
  • Convert decision table rules to test cases where each column of the decision table represents a test case.



PRACTICE PROBLEMS BASED ON CAUSE-EFFECT GRAPH TECHNIQUE-



Problem-01:



Design test cases for the following problem-

If the character of the first column is ‘A’ or ‘B’ and the second column is a number, then the file is considered updated. If the first character is erroneous, then message x should be printed. If the second column is not a number, then message y should be printed.



Solution-



Step-01:



Identify and describe the input conditions (causes) and actions (effect).



The causes represented by letter “C” are as follows-

  • C1 : The character in column 1 is ‘A’
  • C2 : The character in column 1 is ‘B’
  • C3 : The character in column 2 is a number



The effects represented by letter “e” are as follows-

  • e1 : File update is made
  • e2 : Message x is printed
  • e3 : Message y is printed



Step-02:



Build up a cause-effect graph-





Step-03:



Convert cause-effect graph into a decision table-



Test dataCausesEffect
A1A2A3M1M2M3
1000011
2001010
3010001
4011100
5100001
6101100



Problem-02:



Why Cause Effect Graphing Technique is Better Than Any Other Black Box Testing Technique?



Solution-



  • Boundary value analysis and equivalence partitioning do not explore combinations of input circumstances.
  • These only consider the single input conditions.
  • However, combinations of inputs may result in interesting situations.
  • These situations should be tested.
  • By considering all the valid combinations of equivalence classes, there will be large number of test cases.
  • Many of these test cases will not be useful for revealing any new errors.



On the other hand,

  • Cause Effect Graph is a technique that helps in selecting a high-yield set of test cases in a systematic way.
  • It has a beneficial effect in pointing out incompleteness and ambiguities in the specifications.



To gain better understanding about Cause Effect Graph Technique,

Watch this Video Lecture



Get more notes and other study material of Software Engineering.

Watch video lectures by visiting our YouTube channel LearnVidFun.

Cyclomatic Complexity | Calculation | Examples

Cyclomatic Complexity-



Cyclomatic Complexity may be defined as-

  • It is a software metric that measures the logical complexity of the program code.
  • It counts the number of decisions in the given program code.
  • It measures the number of linearly independent paths through the program code.



Cyclomatic complexity indicates several information about the program code-



Cyclomatic ComplexityMeaning
1 – 10
  • Structured and Well Written Code
  • High Testability
  • Less Cost and Effort
10 – 20
  • Complex Code
  • Medium Testability
  • Medium Cost and Effort
20 – 40
  • Very Complex Code
  • Low Testability
  • High Cost and Effort
> 40
  • Highly Complex Code
  • Not at all Testable
  • Very High Cost and Effort



Importance of Cyclomatic Complexity-



  • It helps in determining the software quality.
  • It is an important indicator of program code’s readability, maintainability and portability.
  • It helps the developers and testers to determine independent path executions.
  • It helps to focus more on the uncovered paths.
  • It evaluates the risk associated with the application or program.
  • It provides assurance to the developers that all the paths have been tested at least once.



Properties of Cyclomatic Complexity-



  • It is the maximum number of independent paths through the program code.
  • It depends only on the number of decisions in the program code.
  • Insertion or deletion of functional statements from the code does not affect its cyclomatic complexity.
  • It is always greater than or equal to 1.



Calculating Cyclomatic Complexity-



Cyclomatic complexity is calculated using the control flow representation of the program code.



In control flow representation of the program code,

  • Nodes represent parts of the code having no branches.
  • Edges represent possible control flow transfers during program execution



There are 3 commonly used methods for calculating the cyclomatic complexity-



Method-01:



Cyclomatic Complexity = Total number of closed regions in the control flow graph + 1



Method-02:



Cyclomatic Complexity = E – N + 2



Here-

  • E = Total number of edges in the control flow graph
  • N = Total number of nodes in the control flow graph



Method-03:



Cyclomatic Complexity = P + 1



Here,

P = Total number of predicate nodes contained in the control flow graph



Note-



  • Predicate nodes are the conditional nodes.
  • They give rise to two branches in the control flow graph.



PRACTICE PROBLEMS BASED ON CYCLOMATIC COMPLEXITY-



Problem-01:



Calculate cyclomatic complexity for the given code-

IF A = 354
   THEN IF B > C
        THEN A = B
        ELSE A = C
   END IF
END IF
PRINT A



Solution-



We draw the following control flow graph for the given code-





Using the above control flow graph, the cyclomatic complexity may be calculated as-



Method-01:



Cyclomatic Complexity

= Total number of closed regions in the control flow graph + 1

= 2 + 1

= 3



Method-02:



Cyclomatic Complexity

= E – N + 2

= 8 – 7 + 2

= 3



Method-03:



Cyclomatic Complexity

= P + 1

= 2 + 1

= 3



Problem-02:



Calculate cyclomatic complexity for the given code-

{ int i, j, k;
  for (i=0 ; i<=N ; i++)
  p[i] = 1;
  for (i=2 ; i<=N ; i++)
  {
     k = p[i]; j=1;
     while (a[p[j-1]] > a[k] {
         p[j] = p[j-1];
         j--;
  }
     p[j]=k;
}



Solution-



We draw the following control flow graph for the given code-





Using the above control flow graph, the cyclomatic complexity may be calculated as-



Method-01:



Cyclomatic Complexity

= Total number of closed regions in the control flow graph + 1

= 3 + 1

= 4



Method-02:



Cyclomatic Complexity

= E – N + 2

= 16 – 14 + 2

= 4



Method-03:



Cyclomatic Complexity

= P + 1

= 3 + 1

= 4



Problem-03:



Calculate cyclomatic complexity for the given code-

begin int x, y, power;
      float z;
      input(x, y);
      if(y<0)
      power = -y;
      else power = y;
      z=1;
      while(power!=0)
      {    z=z*x;
           power=power-1;
      } if(y<0)
      z=1/z;
      output(z);
      end



Solution-



We draw the following control flow graph for the given code-





Using the above control flow graph, the cyclomatic complexity may be calculated as-



Method-01:



Cyclomatic Complexity

= Total number of closed regions in the control flow graph + 1

= 3 + 1

= 4



Method-02:



Cyclomatic Complexity

= E – N + 2

= 16 – 14 + 2

= 4



Method-03:



Cyclomatic Complexity

= P + 1

= 3 + 1

= 4



To gain better understanding about Cyclomatic Complexity,

Watch this Video Lecture



Next Article- Cause Effect Graph Technique



Get more notes and other study material of Software Engineering.

Watch video lectures by visiting our YouTube channel LearnVidFun.

Linear Regression Machine Learning | Examples

Linear Regression-



In Machine Learning,

  • Linear Regression is a supervised machine learning algorithm.
  • It tries to find out the best linear relationship that describes the data you have.
  • It assumes that there exists a linear relationship between a dependent variable and independent variable(s).
  • The value of the dependent variable of a linear regression model is a continuous value i.e. real numbers.



Also Read- Machine Learning Algorithms



Representing Linear Regression Model-



Linear regression model represents the linear relationship between a dependent variable and independent variable(s) via a sloped straight line.





The sloped straight line representing the linear relationship that fits the given data best is called as a regression line.

It is also called as best fit line.



Types of Linear Regression-



Based on the number of independent variables, there are two types of linear regression-





  1. Simple Linear Regression
  2. Multiple Linear Regression



1. Simple Linear Regression-



In simple linear regression, the dependent variable depends only on a single independent variable.



For simple linear regression, the form of the model is-

Y = β0 + β1X



Here,

  • Y is a dependent variable.
  • X is an independent variable.
  • β0 and β1 are the regression coefficients.
  • β0 is the intercept or the bias that fixes the offset to a line.
  • β1 is the slope or weight that specifies the factor by which X has an impact on Y.



There are following 3 cases possible-



Case-01: β1 < 0



  • It indicates that variable X has negative impact on Y.
  • If X increases, Y will decrease and vice-versa.





Case-02: β1 = 0



  • It indicates that variable X has no impact on Y.
  • If X changes, there will be no change in Y.





Case-03: β1 > 0



  • It indicates that variable X has positive impact on Y.
  • If X increases, Y will increase and vice-versa.





2. Multiple Linear Regression-



In multiple linear regression, the dependent variable depends on more than one independent variables.



For multiple linear regression, the form of the model is-

Y = β0 + β1X1 + β2X2 + β3X3 + …… + βnXn



Here,

  • Y is a dependent variable.
  • X1, X2, …., Xn are independent variables.
  • β0, β1,…, βn are the regression coefficients.
  • βj (1<=j<=n) is the slope or weight that specifies the factor by which Xj has an impact on Y.



To gain better understanding about Linear Regression,

Watch this Video Lecture



Get more notes and other study material of Machine Learning.

Watch video lectures by visiting our YouTube channel LearnVidFun.

Principal Component Analysis | Dimension Reduction

Dimension Reduction-



In pattern recognition, Dimension Reduction is defined as-

  • It is a process of converting a data set having vast dimensions into a data set with lesser dimensions.
  • It ensures that the converted data set conveys similar information concisely.



Example-



Consider the following example-

  • The following graph shows two dimensions x1 and x2.
  • x1 represents the measurement of several objects in cm.
  • x2 represents the measurement of several objects in inches.





In machine learning,

  • Using both these dimensions convey similar information.
  • Also, they introduce a lot of noise in the system.
  • So, it is better to use just one dimension.



Using dimension reduction techniques-

  • We convert the dimensions of data from 2 dimensions (x1 and x2) to 1 dimension (z1).
  • It makes the data relatively easier to explain.





Benefits-



Dimension reduction offers several benefits such as-

  • It compresses the data and thus reduces the storage space requirements.
  • It reduces the time required for computation since less dimensions require less computation.
  • It eliminates the redundant features.
  • It improves the model performance.



Dimension Reduction Techniques-



The two popular and well-known dimension reduction techniques are-





  1. Principal Component Analysis (PCA)
  2. Fisher Linear Discriminant Analysis (LDA)



In this article, we will discuss about Principal Component Analysis.



Principal Component Analysis-



  • Principal Component Analysis is a well-known dimension reduction technique.
  • It transforms the variables into a new set of variables called as principal components.
  • These principal components are linear combination of original variables and are orthogonal.
  • The first principal component accounts for most of the possible variation of original data.
  • The second principal component does its best to capture the variance in the data.
  • There can be only two principal components for a two-dimensional data set.



PCA Algorithm-



The steps involved in PCA Algorithm are as follows-



Step-01: Get data.

Step-02: Compute the mean vector (µ).

Step-03: Subtract mean from the given data.

Step-04: Calculate the covariance matrix.

Step-05: Calculate the eigen vectors and eigen values of the covariance matrix.

Step-06: Choosing components and forming a feature vector.

Step-07: Deriving the new data set.



PRACTICE PROBLEMS BASED ON PRINCIPAL COMPONENT ANALYSIS-



Problem-01:



Given data = { 2, 3, 4, 5, 6, 7 ; 1, 5, 3, 6, 7, 8 }.

Compute the principal component using PCA Algorithm.



OR



Consider the two dimensional patterns (2, 1), (3, 5), (4, 3), (5, 6), (6, 7), (7, 8).

Compute the principal component using PCA Algorithm.



OR



Compute the principal component of following data-

CLASS 1

X = 2 , 3 , 4

Y = 1 , 5 , 3

CLASS 2

X = 5 , 6 , 7

Y = 6 , 7 , 8



Solution-



We use the above discussed PCA Algorithm-



Step-01:



Get data.

The given feature vectors are-

  • x1 = (2, 1)
  • x2 = (3, 5)
  • x3 = (4, 3)
  • x4 = (5, 6)
  • x5 = (6, 7)
  • x6 = (7, 8)





Step-02:



Calculate the mean vector (µ).



Mean vector (µ)

= ((2 + 3 + 4 + 5 + 6 + 7) / 6, (1 + 5 + 3 + 6 + 7 + 8) / 6)

= (4.5, 5)



Thus,



Step-03:



Subtract mean vector (µ) from the given feature vectors.

  • x1 – µ = (2 – 4.5, 1 – 5) = (-2.5, -4)
  • x2 – µ = (3 – 4.5, 5 – 5) = (-1.5, 0)
  • x3 – µ = (4 – 4.5, 3 – 5) = (-0.5, -2)
  • x4 – µ = (5 – 4.5, 6 – 5) = (0.5, 1)
  • x5 – µ = (6 – 4.5, 7 – 5) = (1.5, 2)
  • x6 – µ = (7 – 4.5, 8 – 5) = (2.5, 3)



Feature vectors (xi) after subtracting mean vector (µ) are-





Step-04:



Calculate the covariance matrix.

Covariance matrix is given by-





Now,





Now,

Covariance matrix

= (m1 + m2 + m3 + m4 + m5 + m6) / 6



On adding the above matrices and dividing by 6, we get-





Step-05:



Calculate the eigen values and eigen vectors of the covariance matrix.

λ is an eigen value for a matrix M if it is a solution of the characteristic equation |M – λI| = 0.

So, we have-





From here,

(2.92 – λ)(5.67 – λ) – (3.67 x 3.67) = 0

16.56 – 2.92λ – 5.67λ + λ2 – 13.47 = 0

λ2 – 8.59λ + 3.09 = 0



Solving this quadratic equation, we get λ = 8.22, 0.38

Thus, two eigen values are λ1 = 8.22 and λ2 = 0.38.



Clearly, the second eigen value is very small compared to the first eigen value.

So, the second eigen vector can be left out.



Eigen vector corresponding to the greatest eigen value is the principal component for the given data set.

So. we find the eigen vector corresponding to eigen value λ1.



We use the following equation to find the eigen vector-

MX = λX

where-

  • M = Covariance Matrix
  • X = Eigen vector
  • λ = Eigen value



Substituting the values in the above equation, we get-





Solving these, we get-

2.92X1 + 3.67X2 = 8.22X1

3.67X1 + 5.67X2 = 8.22X2



On simplification, we get-

5.3X1 = 3.67X2       ………(1)

3.67X1 = 2.55X2     ………(2)



From (1) and (2), X1 = 0.69X2

From (2), the eigen vector is-





Thus, principal component for the given data set is-





Lastly, we project the data points onto the new subspace as-





Problem-02:



Use PCA Algorithm to transform the pattern (2, 1) onto the eigen vector in the previous question.



Solution-



The given feature vector is (2, 1).



The feature vector gets transformed to

= Transpose of Eigen vector x (Feature Vector – Mean Vector)





To gain better understanding about Principal Component Analysis,

Watch this Video Lecture



Get more notes and other study material of Pattern Recognition.

Watch video lectures by visiting our YouTube channel LearnVidFun.

K-Means Clustering Algorithm | Examples

K-Means Clustering-



  • K-Means clustering is an unsupervised iterative clustering technique.
  • It partitions the given data set into k predefined distinct clusters.
  • A cluster is defined as a collection of data points exhibiting certain similarities.





It partitions the data set such that-

  • Each data point belongs to a cluster with the nearest mean.
  • Data points belonging to one cluster have high degree of similarity.
  • Data points belonging to different clusters have high degree of dissimilarity.



K-Means Clustering Algorithm-



K-Means Clustering Algorithm involves the following steps-



Step-01:



  • Choose the number of clusters K.



Step-02:



  • Randomly select any K data points as cluster centers.
  • Select cluster centers in such a way that they are as farther as possible from each other.



Step-03:



  • Calculate the distance between each data point and each cluster center.
  • The distance may be calculated either by using given distance function or by using euclidean distance formula.



Step-04:



  • Assign each data point to some cluster.
  • A data point is assigned to that cluster whose center is nearest to that data point.



Step-05:



  • Re-compute the center of newly formed clusters.
  • The center of a cluster is computed by taking mean of all the data points contained in that cluster.



Step-06:



Keep repeating the procedure from Step-03 to Step-05 until any of the following stopping criteria is met-

  • Center of newly formed clusters do not change
  • Data points remain present in the same cluster
  • Maximum number of iterations are reached



Advantages-



K-Means Clustering Algorithm offers the following advantages-



Point-01:



It is relatively efficient with time complexity O(nkt) where-

  • n = number of instances
  • k = number of clusters
  • t = number of iterations



Point-02:



  • It often terminates at local optimum.
  • Techniques such as Simulated Annealing or Genetic Algorithms may be used to find the global optimum.



Disadvantages-



K-Means Clustering Algorithm has the following disadvantages-

  • It requires to specify the number of clusters (k) in advance.
  • It can not handle noisy data and outliers.
  • It is not suitable to identify clusters with non-convex shapes.



PRACTICE PROBLEMS BASED ON K-MEANS CLUSTERING ALGORITHM-



Problem-01:



Cluster the following eight points (with (x, y) representing locations) into three clusters:

A1(2, 10), A2(2, 5), A3(8, 4), A4(5, 8), A5(7, 5), A6(6, 4), A7(1, 2), A8(4, 9)



Initial cluster centers are: A1(2, 10), A4(5, 8) and A7(1, 2).

The distance function between two points a = (x1, y1) and b = (x2, y2) is defined as-

Ρ(a, b) = |x2 – x1| + |y2 – y1|



Use K-Means Algorithm to find the three cluster centers after the second iteration.



Solution-



We follow the above discussed K-Means Clustering Algorithm-



Iteration-01:



  • We calculate the distance of each point from each of the center of the three clusters.
  • The distance is calculated by using the given distance function.



The following illustration shows the calculation of distance between point A1(2, 10) and each of the center of the three clusters-



Calculating Distance Between A1(2, 10) and C1(2, 10)-



Ρ(A1, C1)

= |x2 – x1| + |y2 – y1|

= |2 – 2| + |10 – 10|

= 0



Calculating Distance Between A1(2, 10) and C2(5, 8)-



Ρ(A1, C2)

= |x2 – x1| + |y2 – y1|

= |5 – 2| + |8 – 10|

= 3 + 2

= 5



Calculating Distance Between A1(2, 10) and C3(1, 2)-



Ρ(A1, C3)

= |x2 – x1| + |y2 – y1|

= |1 – 2| + |2 – 10|

= 1 + 8

= 9



In the similar manner, we calculate the distance of other points from each of the center of the three clusters.



Next,

  • We draw a table showing all the results.
  • Using the table, we decide which point belongs to which cluster.
  • The given point belongs to that cluster whose center is nearest to it.



Given PointsDistance from center (2, 10) of Cluster-01Distance from center (5, 8) of Cluster-02Distance from center (1, 2) of Cluster-03Point belongs to Cluster
A1(2, 10)059C1
A2(2, 5)564C3
A3(8, 4)1279C2
A4(5, 8)5010C2
A5(7, 5)1059C2
A6(6, 4)1057C2
A7(1, 2)9100C3
A8(4, 9)3210C2



From here, New clusters are-



Cluster-01:



First cluster contains points-

  • A1(2, 10)



Cluster-02:



Second cluster contains points-

  • A3(8, 4)
  • A4(5, 8)
  • A5(7, 5)
  • A6(6, 4)
  • A8(4, 9)



Cluster-03:



Third cluster contains points-

  • A2(2, 5)
  • A7(1, 2)



Now,

  • We re-compute the new cluster clusters.
  • The new cluster center is computed by taking mean of all the points contained in that cluster.



For Cluster-01:



  • We have only one point A1(2, 10) in Cluster-01.
  • So, cluster center remains the same.



For Cluster-02:



Center of Cluster-02

= ((8 + 5 + 7 + 6 + 4)/5, (4 + 8 + 5 + 4 + 9)/5)

= (6, 6)



For Cluster-03:



Center of Cluster-03

= ((2 + 1)/2, (5 + 2)/2)

= (1.5, 3.5)



This is completion of Iteration-01.



Iteration-02:



  • We calculate the distance of each point from each of the center of the three clusters.
  • The distance is calculated by using the given distance function.



The following illustration shows the calculation of distance between point A1(2, 10) and each of the center of the three clusters-



Calculating Distance Between A1(2, 10) and C1(2, 10)-



Ρ(A1, C1)

= |x2 – x1| + |y2 – y1|

= |2 – 2| + |10 – 10|

= 0



Calculating Distance Between A1(2, 10) and C2(6, 6)-



Ρ(A1, C2)

= |x2 – x1| + |y2 – y1|

= |6 – 2| + |6 – 10|

= 4 + 4

= 8



Calculating Distance Between A1(2, 10) and C3(1.5, 3.5)-



Ρ(A1, C3)

= |x2 – x1| + |y2 – y1|

= |1.5 – 2| + |3.5 – 10|

= 0.5 + 6.5

= 7



In the similar manner, we calculate the distance of other points from each of the center of the three clusters.



Next,

  • We draw a table showing all the results.
  • Using the table, we decide which point belongs to which cluster.
  • The given point belongs to that cluster whose center is nearest to it.



Given PointsDistance from center (2, 10) of Cluster-01Distance from center (6, 6) of Cluster-02Distance from center (1.5, 3.5) of Cluster-03Point belongs to Cluster
A1(2, 10)087C1
A2(2, 5)552C3
A3(8, 4)1247C2
A4(5, 8)538C2
A5(7, 5)1027C2
A6(6, 4)1025C2
A7(1, 2)992C3
A8(4, 9)358C1



From here, New clusters are-



Cluster-01:



First cluster contains points-

  • A1(2, 10)
  • A8(4, 9)



Cluster-02:



Second cluster contains points-

  • A3(8, 4)
  • A4(5, 8)
  • A5(7, 5)
  • A6(6, 4)



Cluster-03:



Third cluster contains points-

  • A2(2, 5)
  • A7(1, 2)



Now,

  • We re-compute the new cluster clusters.
  • The new cluster center is computed by taking mean of all the points contained in that cluster.



For Cluster-01:



Center of Cluster-01

= ((2 + 4)/2, (10 + 9)/2)

= (3, 9.5)



For Cluster-02:



Center of Cluster-02

= ((8 + 5 + 7 + 6)/4, (4 + 8 + 5 + 4)/4)

= (6.5, 5.25)



For Cluster-03:



Center of Cluster-03

= ((2 + 1)/2, (5 + 2)/2)

= (1.5, 3.5)



This is completion of Iteration-02.



After second iteration, the center of the three clusters are-

  • C1(3, 9.5)
  • C2(6.5, 5.25)
  • C3(1.5, 3.5)



Problem-02:



Use K-Means Algorithm to create two clusters-





Solution-



We follow the above discussed K-Means Clustering Algorithm.

Assume A(2, 2) and C(1, 1) are centers of the two clusters.



Iteration-01:



  • We calculate the distance of each point from each of the center of the two clusters.
  • The distance is calculated by using the euclidean distance formula.



The following illustration shows the calculation of distance between point A(2, 2) and each of the center of the two clusters-



Calculating Distance Between A(2, 2) and C1(2, 2)-



Ρ(A, C1)

= sqrt [ (x2 – x1)2 + (y2 – y1)2 ]

= sqrt [ (2 – 2)2 + (2 – 2)2 ]

= sqrt [ 0 + 0 ]

= 0



Calculating Distance Between A(2, 2) and C2(1, 1)-



Ρ(A, C2)

= sqrt [ (x2 – x1)2 + (y2 – y1)2 ]

= sqrt [ (1 – 2)2 + (1 – 2)2 ]

= sqrt [ 1 + 1 ]

= sqrt [ 2 ]

= 1.41



In the similar manner, we calculate the distance of other points from each of the center of the two clusters.



Next,

  • We draw a table showing all the results.
  • Using the table, we decide which point belongs to which cluster.
  • The given point belongs to that cluster whose center is nearest to it.



Given PointsDistance from center (2, 2) of Cluster-01Distance from center (1, 1) of Cluster-02Point belongs to Cluster
A(2, 2)01.41C1
B(3, 2)12.24C1
C(1, 1)1.410C2
D(3, 1)1.412C1
E(1.5, 0.5)1.580.71C2



From here, New clusters are-



Cluster-01:



First cluster contains points-

  • A(2, 2)
  • B(3, 2)
  • E(1.5, 0.5)
  • D(3, 1)



Cluster-02:



Second cluster contains points-

  • C(1, 1)
  • E(1.5, 0.5)



Now,

  • We re-compute the new cluster clusters.
  • The new cluster center is computed by taking mean of all the points contained in that cluster.



For Cluster-01:



Center of Cluster-01

= ((2 + 3 + 3)/3, (2 + 2 + 1)/3)

= (2.67, 1.67)



For Cluster-02:



Center of Cluster-02

= ((1 + 1.5)/2, (1 + 0.5)/2)

= (1.25, 0.75)



This is completion of Iteration-01.

Next, we go to iteration-02, iteration-03 and so on until the centers do not change anymore.



To gain better understanding about K-Means Clustering Algorithm,

Watch this Video Lecture



Next Article- Principal Component Analysis



Get more notes and other study material of Pattern Recognition.

Watch video lectures by visiting our YouTube channel LearnVidFun.
