**3D Transformations in Computer Graphics-**

We have discussed-

- Transformation is a process of modifying and re-positioning the existing graphics.
- 3D Transformations take place in a three dimensional plane.

In computer graphics, various transformation techniques are-

In this article, we will discuss about 3D Reflection in Computer Graphics.

**3D Reflection in Computer Graphics-**

- Reflection is a kind of rotation where the angle of rotation is 180 degree.
- The reflected object is always formed on the other side of mirror.
- The size of reflected object is same as the size of original object.

Consider a point object O has to be reflected in a 3D plane.

Let-

- Initial coordinates of the object O = (X
_{old}, Y_{old}, Z_{old}) - New coordinates of the reflected object O after reflection = (X
_{new}, Y_{new},Z_{new})

In 3 dimensions, there are 3 possible types of reflection-

- Reflection relative to XY plane
- Reflection relative to YZ plane
- Reflection relative to XZ plane

**Reflection Relative to XY Plane:**

This reflection is achieved by using the following reflection equations-

- X
_{new}= X_{old} - Y
_{new}= Y_{old} - Z
_{new}= -Z_{old}

In Matrix form, the above reflection equations may be represented as-

**Reflection Relative to YZ Plane:**

This reflection is achieved by using the following reflection equations-

- X
_{new}= -X_{old} - Y
_{new}= Y_{old} - Z
_{new}= Z_{old}

In Matrix form, the above reflection equations may be represented as-

**Reflection Relative to XZ Plane:**

This reflection is achieved by using the following reflection equations-

- X
_{new}= X_{old} - Y
_{new}= -Y_{old} - Z
_{new}= Z_{old}

In Matrix form, the above reflection equations may be represented as-

**PRACTICE PROBLEMS BASED ON 3D REFLECTION IN COMPUTER GRAPHICS-**

**Problem-01:**

Given a 3D triangle with coordinate points A(3, 4, 1), B(6, 4, 2), C(5, 6, 3). Apply the reflection on the XY plane and find out the new coordinates of the object.

**Solution-**

Given-

- Old corner coordinates of the triangle = A (3, 4, 1), B(6, 4, 2), C(5, 6, 3)
- Reflection has to be taken on the XY plane

**For Coordinates A(3, 4, 1)**

Let the new coordinates of corner A after reflection = (X_{new}, Y_{new}, Z_{new}).

Applying the reflection equations, we have-

- X
_{new}= X_{old}= 3 - Y
_{new}= Y_{old}= 4 - Z
_{new}= -Z_{old}= -1

Thus, New coordinates of corner A after reflection = (3, 4, -1).

**For Coordinates B(6, 4, 2)**

Let the new coordinates of corner B after reflection = (X_{new}, Y_{new}, Z_{new}).

Applying the reflection equations, we have-

- X
_{new}= X_{old}= 6 - Y
_{new}= Y_{old}= 4 - Z
_{new}= -Z_{old}= -2

Thus, New coordinates of corner B after reflection = (6, 4, -2).

**For Coordinates C(5, 6, 3)**

Let the new coordinates of corner C after reflection = (X_{new}, Y_{new}, Z_{new}).

Applying the reflection equations, we have-

- X
_{new}= X_{old}= 5 - Y
_{new}= Y_{old}= 6 - Z
_{new}= -Z_{old}= -3

Thus, New coordinates of corner C after reflection = (5, 6, -3).

Thus, New coordinates of the triangle after reflection = A (3, 4, -1), B(6, 4, -2), C(5, 6, -3).

**Problem-02:**

Given a 3D triangle with coordinate points A(3, 4, 1), B(6, 4, 2), C(5, 6, 3). Apply the reflection on the XZ plane and find out the new coordinates of the object.

**Solution-**

Given-

- Old corner coordinates of the triangle = A (3, 4, 1), B(6, 4, 2), C(5, 6, 3)
- Reflection has to be taken on the XZ plane

**For Coordinates A(3, 4, 1)**

Let the new coordinates of corner A after reflection = (X_{new}, Y_{new}, Z_{new}).

Applying the reflection equations, we have-

- X
_{new}= X_{old}= 3 - Y
_{new}= -Y_{old}= -4 - Z
_{new}= Z_{old}= 1

Thus, New coordinates of corner A after reflection = (3, -4, 1).

**For Coordinates B(6, 4, 2)**

Let the new coordinates of corner B after reflection = (X_{new}, Y_{new}, Z_{new}).

Applying the reflection equations, we have-

- X
_{new}= X_{old}= 6 - Y
_{new}= -Y_{old}= -4 - Z
_{new}= Z_{old}= 2

Thus, New coordinates of corner B after reflection = (6, -4, 2).

**For Coordinates C(5, 6, 3)**

Let the new coordinates of corner C after reflection = (X_{new}, Y_{new}, Z_{new}).

Applying the reflection equations, we have-

- X
_{new}= X_{old}= 5 - Y
_{new}= -Y_{old}= -6 - Z
_{new}= Z_{old}= 3

Thus, New coordinates of corner C after reflection = (5, -6, 3).

Thus, New coordinates of the triangle after reflection = A (3, -4, 1), B(6, -4, 2), C(5, -6, 3).

To gain better understanding about 3D Reflection in Computer Graphics,
