Projection Operator | Relational Algebra | DBMS

Relational Algebra Operators-



Before you go through this article, make sure that you have gone through the previous article on Introduction to Relational Algebra.



The operators in relational algebra are classified as-





In this article, we will discuss about Projection Operator.



Projection Operator-



  • Projection Operator (π) is a unary operator in relational algebra that performs a projection operation.
  • It displays the columns of a relation or table based on the specified attributes.



Syntax-



π<attribute list>(R)



Example-



Consider the following Student relation-



IDNameSubjectAge
100AshishMaths19
200RahulScience20
300NainaPhysics20
400SameerChemistry21

Student



Then, we have-



Result for Query πName, Age(Student)-



NameAge
Ashish19
Rahul20
Naina20
Sameer21



Result for Query πID , Name(Student)-



IDName
100Ashish
200Rahul
300Naina
400Sameer



Important Points-



Point-01:



  • The degree of output relation (number of columns present) is equal to the number of attributes mentioned in the attribute list.



Point-02:



  • Projection operator automatically removes all the duplicates while projecting the output relation.
  • So, cardinality of the original relation and output relation may or may not be same.
  • If there are no duplicates in the original relation, then the cardinality will remain same otherwise it will surely reduce.



Point-03:



  • If attribute list is a super key on relation R, then we will always get the same number of tuples in the output relation.
  • This is because then there will be no duplicates to filter.



Point-04:



  • Projection operator does not obey commutative property i.e.

π <list2> (π <list1> (R)) ≠ π <list1> (π <list2> (R))



Point-05:



  • Following expressions are equivalent because both finally projects columns of list-1

π <list1> (π <list2> (R)) = π <list1> (R)



Point-06:



  • Selection Operator performs horizontal partitioning of the relation.
  • Projection operator performs vertical partitioning of the relation.



Point-07:



  • There is only one difference between projection operator of relational algebra and SELECT operation of SQL.
  • Projection operator does not allow duplicates while SELECT operation allows duplicates.
  • To avoid duplicates in SQL, we use “distinct” keyword and write SELECT distinct.
  • Thus, projection operator of relational algebra is equivalent to SELECT operation of SQL.



Next Article- Set Theory Operators in Relational Algebra



Get more notes and other study material of Database Management System (DBMS).

Watch video lectures by visiting our YouTube channel LearnVidFun.
