Code Optimization-



Code Optimization is an approach to enhance the performance of the code.



The process of code optimization involves-

  • Eliminating the unwanted code lines
  • Rearranging the statements of the code



Advantages-



The optimized code has the following advantages-

  • Optimized code has faster execution speed.
  • Optimized code utilizes the memory efficiently.
  • Optimized code gives better performance.



Code Optimization Techniques-



Important code optimization techniques are-





  1. Compile Time Evaluation
  2. Common sub-expression elimination
  3. Dead Code Elimination
  4. Code Movement
  5. Strength Reduction



1. Compile Time Evaluation-



Two techniques that falls under compile time evaluation are-



A) Constant Folding-



In this technique,

  • As the name suggests, it involves folding the constants.
  • The expressions that contain the operands having constant values at compile time are evaluated.
  • Those expressions are then replaced with their respective results.



Example-



Circumference of Circle  = (22/7) x Diameter



Here,

  • This technique evaluates the expression 22/7 at compile time.
  • The expression is then replaced with its result 3.14.
  • This saves the time at run time.



B) Constant Propagation-



In this technique,

  • If some variable has been assigned some constant value, then it replaces that variable with its constant value in the further program during compilation.
  • The condition is that the value of variable must not get alter in between.



Example-



pi = 3.14

radius = 10

Area of circle = pi x radius x radius



Here,

  • This technique substitutes the value of variables ‘pi’ and ‘radius’ at compile time.
  • It then evaluates the expression 3.14 x 10 x 10.
  • The expression is then replaced with its result 314.
  • This saves the time at run time.



2. Common Sub-Expression Elimination-



The expression that has been already computed before and appears again in the code for computation

is called as Common Sub-Expression.



In this technique,

  • As the name suggests, it involves eliminating the common sub expressions.
  • The redundant expressions are eliminated to avoid their re-computation.
  • The already computed result is used in the further program when required.



Example-



Code Before OptimizationCode After Optimization
S1 = 4 x i

S2 = a[S1]

S3 = 4 x j

S4 = 4 x i  // Redundant  Expression

S5 = n

S6 = b[S4] + S5

S1 = 4 x i

S2 = a[S1]

S3 = 4 x j

S5 = n

S6 = b[S1] + S5



3. Code Movement-



In this technique,

  • As the name suggests, it involves movement of the code.
  • The code present inside the loop is moved out if it does not matter whether it is present inside or outside.
  • Such a code unnecessarily gets execute again and again with each iteration of the loop.
  • This leads to the wastage of time at run time.



Example-



Code Before OptimizationCode After Optimization
for ( int j = 0 ; j < n ; j ++)

{

x = y + z ;

a[j] = 6 x j;

}

x = y + z ;

for ( int j = 0 ; j < n ; j ++)

{

a[j] = 6 x j;

}



4. Dead Code Elimination-



In this technique,

  • As the name suggests, it involves eliminating the dead code.
  • The statements of the code which either never executes or are unreachable or their output is never used are eliminated.



Example-



Code Before OptimizationCode After Optimization
i = 0 ;

if (i == 1)

{

a = x + 5 ;

}

i = 0 ;



5. Strength Reduction-



In this technique,

  • As the name suggests, it involves reducing the strength of expressions.
  • This technique replaces the expensive and costly operators with the simple and cheaper ones.



Example-



Code Before OptimizationCode After Optimization
B = A x 2B = A + A



Here,

  • The expression “A x 2” is replaced with the expression “A + A”.
  • This is because the cost of multiplication operator is higher than that of addition operator.
