Planar Graph in Graph Theory | Planar Graph Example

Types of Graphs-



Before you go through this article, make sure that you have gone through the previous article on various Types of Graphs in Graph Theory.



We have discussed-

  • A graph is a collection of vertices connected to each other through a set of edges.
  • The study of graphs is known as Graph Theory.





In this article, we will discuss about Planar Graphs.



Planar Graph-



A planar graph may be defined as-



In graph theory,

Planar graph is a graph that can be drawn in a plane such that none of its edges cross each other.



Planar Graph Example-



The following graph is an example of a planar graph-





Here,

  • In this graph, no two edges cross each other.
  • Therefore, it is a planar graph.



Regions of Plane-



The planar representation of the graph splits the plane into connected areas called as Regions of the plane.



Each region has some degree associated with it given as-

  • Degree of Interior region = Number of edges enclosing that region
  • Degree of Exterior region = Number of edges exposed to that region



Example-



Consider the following planar graph-





Here, this planar graph splits the plane into 4 regions- R1, R2, R3 and R4 where-

  • Degree (R1) = 3
  • Degree (R2) = 3
  • Degree (R3) = 3
  • Degree (R4) = 5



Planar Graph Chromatic Number-



  • Chromatic Number of any planar graph is always less than or equal to 4.
  • Thus, any planar graph always requires maximum 4 colors for coloring its vertices.



Planar Graph Properties-



Property-01:



In any planar graph, Sum of degrees of all the vertices = 2 x Total number of edges in the graph





Property-02:



In any planar graph, Sum of degrees of all the regions = 2 x Total number of edges in the graph





Special Cases



Case-01:



In any planar graph, if degree of each region is K, then-



K x |R| = 2 x |E|



Case-02:



In any planar graph, if degree of each region is at least K (>=K), then-



K x |R| <= 2 x |E|



Case-03:



In any planar graph, if degree of each region is at most K (<=K), then-



K x |R| >= 2 x |E|





Property-03:



If G is a connected planar simple graph with ‘e’ edges, ‘v’ vertices and ‘r’ number of regions in the planar representation of G, then-



r = e – v + 2



This is known as Euler’s Formula.

It remains same in all the planar representations of the graph.



Property-04:



If G is a planar graph with k components, then-



r = e – v + (k + 1)



Also Read- Bipartite Graph



PRACTICE PROBLEMS BASED ON PLANAR GRAPH IN GRAPH THEORY-



Problem-01:



Let G be a connected planar simple graph with 25 vertices and 60 edges. Find the number of regions in G.



Solution-



Given-

  • Number of vertices (v) = 25
  • Number of edges (e) = 60



By Euler’s formula, we know r = e – v + 2.



Substituting the values, we get-

Number of regions (r)

= 60 – 25 + 2

= 37



Thus, Total number of regions in G = 37.



Problem-02:



Let G be a planar graph with 10 vertices, 3 components and 9 edges. Find the number of regions in G.



Solution-



Given-

  • Number of vertices (v) = 10
  • Number of edges (e) = 9
  • Number of components (k) = 3



By Euler’s formula, we know r = e – v + (k+1).



Substituting the values, we get-

Number of regions (r)

= 9 – 10 + (3+1)

= -1 + 4

= 3



Thus, Total number of regions in G = 3.



Problem-03:



Let G be a connected planar simple graph with 20 vertices and degree of each vertex is 3. Find the number of regions in G.



Solution-



Given-

  • Number of vertices (v) = 20
  • Degree of each vertex (d) = 3



Calculating Total Number Of Edges (e)-



By sum of degrees of vertices theorem, we have-



Sum of degrees of all the vertices = 2 x Total number of edges

Number of vertices x Degree of each vertex = 2 x Total number of edges

20 x 3 = 2 x e

∴ e = 30



Thus, Total number of edges in G = 30.



Calculating Total Number Of Regions (r)-



By Euler’s formula, we know r = e – v + 2.



Substituting the values, we get-

Number of regions (r)

= 30 – 20 + 2

= 12



Thus, Total number of regions in G = 12.



Problem-04:



Let G be a connected planar simple graph with 35 regions, degree of each region is 6. Find the number of vertices in G.



Solution-



Given-

  • Number of regions (n) = 35
  • Degree of each region (d) = 6



Calculating Total Number Of Edges (e)-



By sum of degrees of regions theorem, we have-



Sum of degrees of all the regions = 2 x Total number of edges

Number of regions x Degree of each region = 2 x Total number of edges

35 x 6 = 2 x e

∴ e = 105



Thus, Total number of edges in G = 105.



Calculating Total Number Of Vertices (v)-



By Euler’s formula, we know r = e – v + 2.



Substituting the values, we get-

35 = 105 – v + 2

∴ v = 72



Thus, Total number of vertices in G = 72.



Problem-05:



Let G be a connected planar graph with 12 vertices, 30 edges and degree of each region is k. Find the value of k.



Solution-



Given-

  • Number of vertices (v) = 12
  • Number of edges (e) = 30
  • Degree of each region (d) = k



Calculating Total Number Of Regions (r)-



By Euler’s formula, we know r = e – v + 2.



Substituting the values, we get-

Number of regions (r)

= 30 – 12 + 2

= 20



Thus, Total number of regions in G = 20.



Calculating Value Of k-



By sum of degrees of regions theorem, we have-



Sum of degrees of all the regions = 2 x Total number of edges

Number of regions x Degree of each region = 2 x Total number of edges

20 x k = 2 x 30

∴ k = 3



Thus, Degree of each region in G = 3.



Problem-06:



What is the maximum number of regions possible in a simple planar graph with 10 edges?



Solution-



In a simple planar graph, degree of each region is >= 3.

So, we have 3 x |R| <= 2 x |E|.



Substituting the value |E| = 10, we get-

3 x |R| <= 2 x 10

|R| <= 6.67

|R| <= 6



Thus, Maximum number of regions in G = 6.



Problem-07:



What is the minimum number of edges necessary in a simple planar graph with 15 regions?



Solution-



In a simple planar graph, degree of each region is >= 3.

So, we have 3 x |R| <= 2 x |E|.



Substituting the value |R| = 15, we get-

3 x 15 <= 2 x |E|

|E| >= 22.5

|E| >= 23



Thus, Minimum number of edges required in G = 23.



To gain better understanding about Planar Graphs in Graph Theory,
