3 Way Handshake | TCP Connection

Transmission Control Protocol-



Before you go through this article, make sure that you have gone through the previous article on TCP in Networking.



We have discussed-

  • TCP establishes an end to end connection between the sender and receiver.
  • This connection is established before exchanging the data.
  • TCP connection is reliable and ensures in order delivery.



Also Read- TCP Header



In this article, we will discuss how a TCP connection is established.



3 Way Handshake-



Three Way Handshake is a process used for establishing a TCP connection.



Consider-

  • Client wants to establish a connection with the server.
  • Before Three Way Handshake, both client and server are in closed state.



TCP Handshake involves the following steps in establishing the connection-



Step-01: SYN-



For establishing a connection,

  • Client sends a request segment to the server.
  • Request segment consists only of TCP Header with an empty payload.
  • Then, it waits for a reply segment from the server.





Request segment contains the following information in TCP header-

  1. Initial sequence number
  2. SYN bit set to 1
  3. Maximum segment size
  4. Receiving window size



1. Initial Sequence Number-



  • Client sends the initial sequence number to the server.
  • It is contained in the sequence number field.
  • It is a randomly chosen 32 bit value.



2. SYN Bit Set To 1-



Client sets SYN bit to 1 which indicates the server-

  • This segment contains the initial sequence number used by the client.
  • It has been sent for synchronizing the sequence numbers.



Also Read- TCP Sequence Number



3. Maximum Segment Size (MSS)-



  • Client sends its MSS to the server.
  • It dictates the size of the largest data chunk that client can send and receive from the server.
  • It is contained in the Options field.



4. Receiving Window Size-



  • Client sends its receiving window size to the server.
  • It dictates the limit of unacknowledged data that can be sent to the client.
  • It is contained in the window size field.



Step-02: SYN + ACK-



After receiving the request segment,

  • Server responds to the client by sending the reply segment.
  • It informs the client of the parameters at the server side.





Reply segment contains the following information in TCP header-

  1. Initial sequence number
  2. SYN bit set to 1
  3. Maximum segment size
  4. Receiving window size
  5. Acknowledgment number
  6. ACK bit set to 1



1. Initial Sequence Number-



  • Server sends the initial sequence number to the client.
  • It is contained in the sequence number field.
  • It is a randomly chosen 32 bit value.



2. SYN Bit Set To 1-



Server sets SYN bit to 1 which indicates the client-

  • This segment contains the initial sequence number used by the server.
  • It has been sent for synchronizing the sequence numbers.



3. Maximum Segment Size (MSS)-



  • Server sends its MSS to the client.
  • It dictates the size of the largest data chunk that server can send and receive from the client.
  • It is contained in the Options field.



4. Receiving Window Size-



  • Server sends its receiving window size to the client.
  • It dictates the limit of unacknowledged data that can be sent to the server.
  • It is contained in the window size field.



5. Acknowledgement Number-



  • Server sends the initial sequence number incremented by 1 as an acknowledgement number.
  • It dictates the sequence number of the next data byte that server expects to receive from the client.



6. ACK Bit Set To 1-



  • Server sets ACK bit to 1.
  • It indicates the client that the acknowledgement number field in the current segment is valid.



Step-03: ACK-



After receiving the reply segment,

  • Client acknowledges the response of server.
  • It acknowledges the server by sending a pure acknowledgement.





With these, a Full Duplex connection is established.



Important Points-



Point-01:



In step-01 and step-02-

  • The connection parameters are established for the first side.
  • They are acknowledged by the second side.



In step-02 and step-03-

  • The connection parameters are established for the second side.
  • They are acknowledged by the first side.



Point-02:



Connection establishment phase consume 1 sequence number of both the sides.



  • Request segment consumes 1 sequence number of the requester.
  • Reply segment consumes 1 sequence number of the respondent.
  • Pure acknowledgements do not consume any sequence number.



Point-03:



Pure acknowledgement for the reply segment is not necessary.



This is because-

  • If client sends the data packet immediately, then it will be considered as an acknowledgement.
  • It means that in the first two steps only, the full duplex connection is established.



Point-04:



For all the segments except the request segment, ACK bit is always set to 1.



This is because-

  • For the request segment, acknowledgement number field will always be invalid.
  • For all other segments, acknowledgement number field will always be valid.



Point-05:



Certain parameters are negotiated during connection establishment.



The negotiation can be on setting the values of following parameters-

  1. Window size
  2. Maximum segment size
  3. Timer values



Point-06:



In any TCP segment,

  • If SYN bit = 1 and ACK bit = 0, then it must be the request segment.
  • If SYN bit = 1 and ACK bit = 1, then it must be the reply segment.
  • If SYN bit = 0 and ACK bit = 1, then it can be the pure ACK or segment meant for data transfer.
  • If SYN bit = 0 and ACK bit = 0, then this combination is not possible.



Point-07:



  • The combination SYN bit = 0 and ACK bit = 0 is not possible.
  • It is because SYN bit = 0 signifies it is not the request segment and reply segment.
  • For all other segments, ACK bit is always set to 1.



Point-08:



  • Consider sender sends the segments of size greater than MSS of receiver.
  • Then, they are first fragmented first at the receiver side.
  • It causes an extra overhead.



Point-09:



  • There is no dedicated field for sending MSS in TCP header.
  • This is because MSS has to informed only once.
  • So, if dedicated field would be present, then sending it each time would not be required.
  • For this reason, MSS is informed once using Options field.



Also Read- TCP Connection Termination



PRACTICE PROBLEMS BASED ON THREE WAY HANDSHAKE-



Problem-01:



SYN = 0 and ACK = 1 indicates-

  1. Open connection packet
  2. Open connection ACK
  3. Data packet
  4. ACK packet



Solution-



Options (C) and (D) are correct.



Problem-02:



An acknowledgement by TCP sender guarantees-

  1. Data has been delivered to the application
  2. Data has been received by TCP module
  3. Data has been received by application interface
  4. None of the above



Solution-



Option (A) is correct.



To gain better understanding about Three Way Handshake,

Watch this Video Lecture



Next Article- TCP Retransmission



Get more notes and other study material of Computer Networks.

Watch video lectures by visiting our YouTube channel LearnVidFun.
