Non Deterministic Finite Automata | NFA

Non-Deterministic Finite Automata-



Non-Deterministic Finite Automata (NDFA / NFA) is an automata in which

for some current state and input symbol, there exists more than one next output states.



It is also known as Non-Deterministic Finite Accepter (NFA).



Formal Definition-



Non-Deterministic Finite Automata is defined by the quintuple-

M = (Q, ∑, δ, q0, F)



where-

  • Q = finite set of states
  • ∑ = non-empty finite set of symbols called as input alphabets
  • δ : Q x ∑ → 2Q is a total function called as transition function
  • q0 ∈ Q is the initial state
  • F ⊆ Q is a set of final states



Example of Non-Deterministic Finite Automata Without Epsilon-



Following automata is an example of Non-Deterministic Finite Automata without epsilon-





The above NFA can be defined in form of five tuples as-

{ {A, B, C, D, E, F}, {a, b, c}, δ, A, {D, F} }



where-

  • {A, B, C, D, E, F} refers to the set of states
  • {a, b, c} refers to the set of input alphabets
  • δ refers to the transition function
  • A refers to the the initial state
  • {D, F} refers to the set of final states



Transition function δ is defined as-

  • δ (A, a) = B
  • δ (A, a) = E
  • δ (B, b) = C
  • δ (C, c) = D
  • δ (E, b) = F
  • δ (F, c) = E



Transition Table for the above Non-Deterministic Finite Automata is-



States / Alphabetsabc
A{B, F}
BC
CD
D
EF
FE



Example of Non-Deterministic Finite Automata With Epsilon-



Following automata is an example of Non-Deterministic Finite Automata with epsilon-





The above NFA can be defined in form of five tuples as-

{ {A, B, C}, {0, 1}, δ, A, {A} }



where-

  • {A, B, C} refers to the set of states
  • {0, 1} refers to the set of input alphabets
  • δ refers to the transition function
  • A refers to the the initial state
  • {A} refers to the set of final states



Transition function δ is defined as-

  • δ (A, 1) = B
  • δ (A, ∈) = C
  • δ (B, 0) = A
  • δ (B, 0) = C
  • δ (B, 1) = C



Transition Table for the above Non-Deterministic Finite Automata is-



States / Alphabets01
ABC
B{A, C}C
C



Dead Configuration or Trap State-



In Non-Deterministic Finite Automata,

  • The result of a transition function may be empty.
  • In such a case, automata gets stopped forcefully after entering that configuration.
  • This type of configuration is known as dead configuration.
  • The string gets rejected after entering the dead configuration.



Equivalence of DFA and NFA-



Two finite accepters are said to be equal in power if they both accepts the same language.

DFA and NFA are both exactly equal in power.



Example-



Consider a language L(M) = { (10)n : n >= 0 }



Equivalent NFA for the language L(M) is-





Equivalent DFA for the language L(M) is-





  • Both the above automata accepts the same language L(M).
  • Thus, both are equal in power.



Important Points



It is important to note the following points-

  • Both DFA and NFA are exactly same in power.
  • For any regular language, both DFA and NFA can be constructed.
  • There exists an equivalent DFA corresponding to every NFA.
  • Every NFA can be converted into its equivalent DFA.
  • There exists no NFA that can not be converted into its equivalent DFA.
  • Every DFA is a NFA but every NFA is not a DFA.



Acceptance by NFA-



A string ‘w’ is said to be accepted by a NFA if

there exists at least one transition path on which we start at initial state and ends at final state.

δ* (q0, w) = F



Example-



Consider the following NFA-





For the string w = ab,

  • There exists two transition paths.
  • One transition path starts at initial state and ends at final state.
  • Therefore, string w = ab is accepted by the NFA.



To gain better understanding about Non-Deterministic Finite Automata,

Watch this Video Lecture



Next Article- Converting NFA to DFA
