Depth First Search Algorithm | DFS Example

Depth First Search-



  • Depth First Search or DFS is a graph traversal algorithm.
  • It is used for traversing or searching a graph in a systematic fashion.
  • DFS uses a strategy that searches “deeper” in the graph whenever possible.
  • Stack data structure is used in the implementation of depth first search.



DFS Example-



Consider the following graph-





The depth first search traversal order of the above graph is-

A, B, E, F, C, D



Depth First Search Algorithm-



DFS (V,E)



for each vertex u in V[G]

do color[v] ← WHITE

π[v] ← NIL

time ← 0

for each vertex v in V[G]

do if color[v] ← WHITE

then Depth_First_Search(v)



Depth_First_Search (v)



color[v] ← GRAY

time ← time + 1

d[v] ← time

for each vertex u adjacent to v

do if color[u] ← WHITE

π[u] ← v

Depth_First_Search(u)

color[v] ← BLACK

time ← time + 1

f[v] ← time



Explanation-



The above depth first search algorithm is explained in the following steps-



Step-01



Create and maintain 4 variables for each vertex of the graph.

For any vertex ‘v’ of the graph, these 4 variables are-



1. color[v]-



  • This variable represents the color of the vertex ‘v’ at the given point of time.
  • The possible values of this variable are- WHITE, GREY and BLACK.
  • WHITE color of the vertex signifies that it has not been discovered yet.
  • GREY color of the vertex signifies that it has been discovered and it is being processed.
  • BLACK color of the vertex signifies that it has been completely processed.



2. Π[v]-



This variable represents the predecessor of vertex ‘v’.



3. d[v]-



This variable represents a timestamp when a vertex ‘v’ is discovered.



3. f[v]-



This variable represents a timestamp when the processing of vertex ‘v’ is completed.



Step-02



For each vertex of the graph, initialize the variables as-

  • color[v] = WHITE
  • π[v] = NIL
  • time = 0     (Global Variable acting as a timer)



Step-03



Repeat the following procedure until all the vertices of the graph become BLACK-

Consider any white vertex ‘v’ and call the following Depth_First_Search function on it.



Depth_First_Search (G,v)



1. color[v] = GRAY

2. time = time + 1

3. d[v] = time

4. For each adjacent WHITE vertex ‘u’ of ‘v’, set π[u] = v and call Depth_First_Search (G,u)

5. color[v] = BLACK

6. time = time + 1

7. f[v] = time



DFS Time Complexity-



The total running time for Depth First Search is θ (V+E).



Types of Edges in DFS-



After a DFS traversal of any graph G, all its edges can be put in one of the following 4 classes-





  1. Tree Edge
  2. Back Edge
  3. Forward Edge
  4. Cross Edge



1. Tree Edge-



  • A tree edge is an edge that is included in the DFS tree.



2. Back Edge-



An edge from a vertex ‘u’ to one of its ancestors ‘v’ is called as a back edge.

A self-loop is considered as a back edge.



A back edge is discovered when-

  • DFS tries to extend the visit from a vertex ‘u’ to vertex ‘v’
  • And vertex ‘v’ is found to be an ancestor of vertex ‘u’ and grey at that time.



3. Forward Edge-



An edge from a vertex ‘u’ to one of its descendants ‘v’ is called as a forward edge.



A forward edge is discovered when-

  • DFS tries to extend the visit from a vertex ‘u’ to a vertex ‘v’
  • And finds that color(v) = BLACK and d(v) > d(u).



4. Cross Edge-



An edge from a vertex ‘u’ to a vertex ‘v’ that is neither its ancestor nor its descendant is called as a cross edge.



A cross edge is discovered when-

  • DFS tries to extend the visit from a vertex ‘u’ to a vertex ‘v’
  • And finds that color(v) = BLACK and d(v) < d(u).



PRACTICE PROBLEM BASED ON DEPTH FIRST SEARCH-



Problem-



Compute the DFS tree for the graph given below-





Also, show the discovery and finishing time for each vertex and classify the edges.



Solution-



Initially for all the vertices of the graph, we set the variables as-

  • color[v] = WHITE
  • π[v] = NIL
  • time = 0 (Global)



Let us start processing the graph from vertex U.



Step-01:



  • color[U] = GREY
  • time = 0 + 1 = 1
  • d[U] = 1





Step-02:



  • π[V] = U
  • color[V] = GREY
  • time = 1 + 1 = 2
  • d[V] = 2





Step-03:



  • π[Y] = V
  • color[Y] = GREY
  • time = 2 + 1 = 3
  • d[Y] = 3





Step-04:



  • π[X] = Y
  • color[X] = GREY
  • time = 3 + 1 = 4
  • d[X] = 4





Step-05:



When DFS tries to extend the visit from vertex X to vertex V, it finds-

  • Vertex V is an ancestor of vertex X since it has already been discovered
  • Vertex V is GREY in color.



Thus, edge XV is a back edge.





Step-06:



  • color[X] = BLACK
  • time = 4 + 1 = 5
  • f[X] = 5





Step-07:



  • color[Y] = BLACK
  • time = 5 + 1 = 6
  • f[Y] = 6





Step-08:



  • color[V] = BLACK
  • time = 6 + 1 = 7
  • f[V] = 7





Step-09:



When DFS tries to extend the visit from vertex U to vertex X, it finds-

  • Vertex X has already been completely processed i.e. vertex X has finished and is black.
  • But vertex U has still not finished.



Alternatively,

When DFS tries to extend the visit from vertex U to vertex X, it finds-

  • Color(X) = BLACK
  • d(X) > d(U)



Thus, edge UX is a forward edge.





Step-10:



  • color[U] = BLACK
  • time = 7 + 1 = 8
  • f[U] = 8





Step-11:



  • color[W] = GREY
  • time = 8 + 1 = 9
  • d[W] = 9





Step-12:



When DFS tries to extend the visit from vertex W to vertex Y, it finds-

  • Vertex Y has already been completely processed i.e. vertex Y has finished.
  • Vertex Y is neither a descendant nor an ancestor of vertex W.



Alternatively,

When DFS tries to extend the visit from vertex W to vertex Y, it finds-

  • Color(Y) = BLACK
  • d(Y) < d(W)



Thus, edge WY is a cross edge.





Step-13:



  • π[Z] = W
  • color[W] = GREY
  • time = 9 + 1 = 10
  • d[W] = 10





Step-14:



Since, self-loops are considered as back edges.

Therefore, self-loop present on vertex Z is considered as a back edge.





Step-15:



  • color[Z] = BLACK
  • time = 10 + 1 = 11
  • f[Z] = 11





Step-16:



  • color[W] = BLACK
  • time = 11 + 1 = 12
  • f[W] = 12





Since all the vertices have turned black, so we stop.

This is how a given graph is traversed using Depth First Search (DFS) technique.
