Job sequencing with deadlines

Job sequencing with deadlines-



The sequencing of jobs on a single processor with deadline constraints is named as job sequencing with deadlines.



Problem-



You are given a set of jobs where each job has a defined deadline and some profit associated with it. The profit of that job is given only when that job is completed within its deadline.

The problem is-

“How can the total profit be maximized if only one job can be completed at a time?”



Constraints-



  • Only one processor is available for processing all jobs.
  • Processor takes one unit of time to complete a job.
  • All the jobs have to be completed within their respective deadlines to obtain the profits associated with them.



Solution-



For the given problem,

  • A feasible solution would be a subset of jobs where each job of the subset gets completed within its deadline.
  • Value of the feasible solution would be the sum of profits of all the jobs contained in the subset.
  • An optimal solution of the problem would be a feasible solution which gives the maximum profit.



Job Sequencing with deadlines Greedy Algorithm-



We adopt a greedy algorithm to determine how the next job is selected for an optimal solution. The greedy algorithm described below always gives an optimal solution to the job sequencing problem.



Step-01:



Sort all the given jobs in the decreasing order of their profits.



Step-02:



Check the value of maximum deadline. Then, draw a Gantt chart where maximum time on Gantt chart is the value of maximum deadline.



Step-03:



Pick up the jobs one by one and then put them on the Gantt chart as far as possible from 0 (starting point) such that the job gets completed before its deadline.



The following practice problem illustrates these steps in detail.



PRACTICE PROBLEM BASED ON JOB SEQUENCING WITH DEADLINES



Problem-



Given the following jobs, their deadlines and associated profits as shown-



JobsJ1J2J3J4J5J6
Deadlines533242
Profits200180190300120100



Answer the following questions-

  1. Write the optimal schedule that gives maximum profit.
  2. Are all the jobs completed in the optimal schedule?
  3. What is the maximum earned profit?



Solution-



Step-01:



Sort all the given jobs in the decreasing order of their profits-



JobsJ4J1J3J2J5J6
Deadlines253342
Profits300200190180120100



Step-02:



Value of maximum deadline = 5

So, draw a Gantt chart with maximum time on Gantt chart = 5 units as shown-





Step-03:



Now, we will take each job one by one in the order they appear in step-01 and place them on Gantt chart as far as possible from 0 (starting point)



  • First, we take job J4.
  • Since, its deadline is 2, so we place it in the first empty cell before deadline 2 as-





  • Now, we take job J1.
  • Since, its deadline is 5, so we place it in the first empty cell before deadline 5 as-





  • Now, we take job J3.
  • Since, its deadline is 3, so we place it in the first empty cell before deadline 3 as-





  • Now, we take job J2.
  • Since, its deadline is 3, so we place it in the first empty cell before deadline 3.
  • Since, the second and third cells are already filled, so we place job J2 in the first cell as-





  • Now, we take job J5.
  • Since, its deadline is 4, so we place it in the first empty cell before deadline 4 as-





Now,

  • The only job left is job J6 whose deadline is 2.
  • All the slots before deadline 2 are already occupied.
  • Thus, job J6 can not be completed.



Now, the given questions may be answered as-



Part-01:



The optimal schedule is-

J2  , J4 , J3 , J5 , J1

This is the required order in which the jobs must be completed in order to obtain the maximum profit.



Part-02:



  • All the jobs are not completed in the optimal schedule.
  • This is because job J6 could not be completed within its deadline.



Part-03:



Maximum earned profit

= Sum of profits of all jobs in optimal schedule

= Profit of job J2 + Profit of job J4 + Profit of job J3 + Profit of job J5 + Profit of job J1

= 180 + 300 + 190 + 120 + 200

= 990 units



Get more notes and other study material of Design and Analysis of Algorithms (DAA).

Watch video lectures by visiting our YouTube channel LearnVidFun.
